Description
Our 2 tier heavy duty workstations are made and designed to last a lifetime. Made with 3mm steel to ensure quality and support heavy loads, finished with powder coated Blue colour (RAL5005) and Orange (RAL2004) and tested for load, stability and rigidity.
Available in different sizes, easy to assemble and can hold loads up to 1200Kg.
Shelves are high quality, high density 22mm chipboard that sit within the beams.
Top shelf 250mm bottom shelf 600 or 900mm
Colour of chipboard may vary from picture.
Sizes:
1250 (H) x 1000 (W) x 600 (D)
1250 (H) x 1000 (W) x 900 (D)
1250 (H) x 1500 (W) x 900 (D)
1250 (H) x 1500 (W) x 600 (D)
1250 (H) x 2000 (W) x 900 (D)
1250 (H) x 2000 (W) x 600 (D)
1250 (H) x 2500 (W) x 900 (D)
1250 (H) x 2500 (W) x 600 (D)
Top shelf 400mm deep on all sizes.
Other sizes available on request
Made in Britain
Delivery - 5 days
How to assemble:
Average build time: 10 - 15 mins per bay (requires two people).
Tools required: 2 x 13mm/adjustable spanners and a rubber mallet
Step 1 – Build end frames as per relevant drawing attached
Step 2 – Stand built end frames upright and support vertically
Step 3 – Locate beams into slots in upright in the required position starting at the bottom
Step 4 – Fit remaining beams to create shelf heights as required
Step 5 – Locate safety pins into the holes at the end of each beam to prevent dis-lodgement.
Step 6 – Locate shelves onto beams using the correct number of shelf supports as shown below.
Step 7 – Fix to floor or wall if required according to the 5:1 height to depth ratio.
